撮影用テストチャート(反射型)
Test Chart for taking a picture (Reflection photographing)

反射型テストチャートは、壁などに貼り付けてカメラなどの被検レンズユニットで撮影し、そのレンズの解像力を評価するために使用します。撮影用テストチャートは主にカメラレンズに使用します。
P : ピッチ R : 解像力

Reflection-type chart is used attached on wall, to photograph testing lenses such as camera in unit and to evaluate resolution power.
Test Chart for Photographing is mainly used for camera lenses.
P : Pitch R : Resolving power

[ T-03535(N) ]

[ T-03535(N) ]

P=0.35~3.5mm
R=2.9~0.29 line/mm

[ T-410(N) ]

[ T-410(N) ]

P=4~10mm
R=0.25~0.1 line/mm

[ T JIS-A(N) ]

[ T JIS-A(N) ]

P=3.55~6.31mm
R=0.28~0.16 line/mm

[ T JIS-BE(N) ]

[ T JIS-BE(N) ]

P=0.22~3.16mm
R=4.55~0.32 line/mm

反射型テストチャートの撮影 Photographing to reflection type char

[ T JIS-A(N) ]

マイクロ用テストチャート(反射型)
Test Chart for micro camera (Reflection type)

マイクロ用テストチャートは、撮影して被検レンズの解像力を評価するために使用します。主に、デジタルカメラレンズ・短焦点カメラレンズに使用します。
P : ピッチ R : 解像力

Test Chart for micro lens is used for photographing and evaluating the resolution power of testing lens.
It is mainly used for digital camera lens, short-focus camera lens.
P : Pitch R : Resolving power

ポジとネガ
Positive type and Negative type

ポジとネガ   Positive type and Negative type

型式末尾の(P)はポジチャート、(N)はネガチャートを表します。

[ M118(P) ]

[ M118(P) ]

P=1~0.56mm
R=1~1.8 line/mm

[ M228(P) ]

[ M228(P) ]

P=0.5~0.036mm
R=2~28 line/mm

[ 403M110(P) ]

[ 403M110(P) ]

P=1~0.1mm
R=1~10 line/mm

[ 3M110(P) ]

[ 3M110(P) ]

P=1~0.1mm
R=1~10 line/mm

[ 3M550(P) ]

[ 3M550(P) ]

P=0.2~0.02mm
R=5~50 line/mm

4K、8K解像力チャート(反射型)
Resolving power chart

ISO12233準拠反射型撮影用テストチャートは、壁などに貼り付けてカメラなどの被検レンズユニットで撮影し、解像力をはじめ各性能を評価するために使用します。

An ISO 1223-compatible reflective test chart is used to evaluate many performance aspects of test lenses. Put this chart on a wall or other flat surface and take a picture of this chart with a camera equipped with a test lens. This will let you evaluate the resolution and other performance aspects of test lenses.


HR916348(ビデオカメラ用)

HYRes3.1での測定の様子

HYRes3.1での測定の様子
the situation of measurement by HYRes3.

【SPECIFICATIONS】
規格 ISO12233
サイズ 300 × 533mm
アスペクト比 1:1/3:4/2:3/9:16
解像度 300~4800TV 本
光学濃度 1.85
反射比 70

ソフトウェアの動作条件については、CIPAのダウンロードページを確認の上、ご使用ください。

if attached to the operatine condition of software, please use it after checkine the download page of CIPA.


HR23348(スチルカメラ用)

8K解像度 テストチャート
HYRes3.1での測定の様子

HYRes3.1での測定の様子
the situation of measurement by HYRes3.

【SPECIFICATIONS】
規格 ISO12233
サイズ 200 × 300mm
アスペクト比 1:1/4:3/2:3
解像度 300~4800TV 本
光学濃度 1.85
反射比 70

ソフトウェアの動作条件については、CIPAのダウンロードページを確認の上、ご使用ください。

if attached to the operatine condition of software, please use it after checkine the download page of CIPA.


HR916424(多用途用)

4K解像度 テストチャート
HYRes3.1での測定の様子

HYRes3.1での測定の様子
the situation of measurement by HYRes3.

【SPECIFICATIONS】
規格 ISO12233
サイズ 150 × 266.7mm
アスペクト比 1:1/4:3/2:3/9:16
解像度 400~2400TV 本
光学濃度 1.85
反射比 70

ソフトウェアの動作条件については、CIPAのダウンロードページを確認の上、ご使用ください。

if attached to the operatine condition of software, please use it after checkine the download page of CIPA.
